User Guide DDOC0099-000-AH
DTS1 CSfC 7 - 17 Operation
© 2020 Curtiss-Wright Defense Solutions Revision 4.0
Example
7.8 Built In Test
7.8.1 IBIT (Initiated BIT)
NOTE
Results will be provided as 1 (Pass), 0 (Fail), and NA (function not active)
The ibit command provides a snap-shot of the DTS1 status. To view status, type ibit and press
E
NTER key.
• IBIT_MON line provides results for system monitor subsystem.
• IBIT_ETH line provides results for Ethernet subsystem.
• IBIT_RMC# line provides results for RMC module in slot #
Example
7.8.2 MBIT (Maintenance BIT)
The mbit command is used with various options to perform maintenance built-in tests. Several of
these tests either destroy or may destroy data on the RMC module. As a result, to perform these
tests use of a --go option along with command option is required.
cw_dts> sens
[sens]
_______________________________VOLTAGES___________________________
SENSOR VALUE MIN MAX STATUS
V_ETH_CORE 1.04 1.00 1.10 Pass
V_ETH_VDDa 1.86 1.70 2.10 Pass
V_ETH_VDDd 1.90 1.70 2.10 Pass
V_ETH_VDD 1.81 1.60 2.00 Pass
V_MAIN_12V 11.98 11.00 13.00 Pass
V_V5.0 4.89 4.50 5.50 Pass
V_V3.3 3.31 3.00 3.60 Pass
V_RMC0_12 12.02 11.00 13.00 Pass
V_RMC0_5 5.03 4.50 5.50 Pass
V_RMC0_3 3.30 3.00 3.60 Pass
CAP_OK 1 - - Pass
V_CRYPT 3.67 3.40 3.90 Pass
_________________________TEMPERATURES_____________________________
SENSOR VALUE MIN MAX STATUS
T_COMF 37 -45 90 Pass
T_COMM 42 -45 90 Pass
T_COMR 38 -45 90 Pass
T_VREG 43 -45 90 Pass
T_PSUT 38 -45 90 Pass
T_PSUB 38 -45 90 Pass
T_RMC0_DR 35 -45 90 Pass
T_RMC0_DF 38 -45 90 Pass
T_CRYPT 40 -45 90 Pass
___________________ADVANTECH HWMON SENSORS________________________
SENSOR VALUE MIN MAX STATUS
V_12 11.79 11.00 1 Pass
CORE0 46 0 110 Pass
CORE1 46 0 110 Pass
CORE2 46 0 110 Pass
CORE3 46 0 110 Pass
[!sens] OK
cw_dts> ibit
[ibit]
IBIT_MON: mcu=1/0 i2c=1/0 volt=1/0 status=OK/ERR
IBIT_ETH: eth0=1/0 eth1=1/0
IBIT_RMC0: volt=1/0/NA ata=1/0/NA smart=1/0/NA status=OK/ERR
[!ibit] <summary>
