7
-10
HAULER 4X4 DIESEL
(1) Grease Fitting (Front Axle Drive Shaft
Around Gear Box)
UUVo776D
It is located on the spline area of
front axle drive shaft around the gear
box. Raise up the cargo bet to feed
the grease to this tting.
UUVo778A
UUVo779A
The remaining 12 are located in the
rear suspension section. Remove the
rear wheels to add grease.
(1) Grease tting
