7. If the parking brake pads should
be replaced with new ones or ab-
normal wear is found on the disc,
contact your Dealer.
ADJUSTING SUSPENSION (AB)
1. Park the vehicle on level ground
and apply the parking brake rmly.
2. Unscrew the nuts of one of the
rear wheels only 1 turn.
3. Lift the vehicle with a hydraulic
jack and then support the vehicle
with the safety stand. Then, lower
the hydraulic jack so that the vehi-
cle chassis sits on the stand.
(1) Wheel Nut
The rear suspension equipped on
this vehicle is adjustable, to allow for
ride quality and weight hauling. To
adjust the suspension, perform the
following steps:
4. Unscrew the wheel nuts complete-
ly to remove the wheel.
(1) Hole
5. Fit a special service tool to the
hole and turn it to adjust the spring
load and stroke.
A direction(soft): suitable for
driving mountainous area fre-
quently.
B direction(hard): suitable for
transporting cargo frequently.
NOTE
UUVo746A
UUVo750A
To Next Page
