HAULER 4X4 DIESEL
CHECKING SPARK ARRESTER OF
EXHAUST PIPE (IF EQUIPPED) (R)
1. Park the vehicle on level ground
and apply the parking brake rmly.
2. Stop the engine and let the engine
cooled down sufciently.
3. Raise the cargo bed and support it
with the support rod.
CHECKING AND CHANGING GEARBOX OIL (S)
1. Park the vehicle on level ground
and apply the parking brake rmly.
2. Stop the engine and let the engine
cooled down sufciently.
3. Loosen the xing bolt and then re-
move the spark arrester.
4. Apply WD-40 or equivalent to the
inner side and blow any residual
with compressed air. Do not blow
with compressed air too closely, or
the lter can be damaged.
5. If the lter is damaged, replace the
spark arrester with a new one.
(1) Filler plug
4. Clean around filler plug, then re-
move the ller plug.
5. Check that the gearbox surface
is not hot. Then, check the oil lev-
el and condition with a nger bent
slightly. If you cannot reach the oil,
it means the oil level is low. Add oil
as needed to ll.
6. If the color or viscosity of the oil is
not normal or it is at the oil change
interval, change the oil.
(1) Drain plug
7. To change oil, place a container
with wide opening under the drain
plug. Then, remove the drain plug.
8. After draining all the oil, install the
drain plug rmly.
9. W h e n a d d in g n ew o i l , a d d i t
through a long hose into the fill
plug location. Fill till oil starts to
spill out of ller plug hole.

You can get burnt by touch-
ing hot parts, such as the muf-
fler. Wait until hot parts have
cooled down after stopping
the engine.
WARNING
UUVo734A
UUVo735A
