ITEMS HAULER 4X4 DIESEL REMARKS
Driving unit
Main shift
CVT (Continuous Variable Transmission with belt)
Range shift High / Low / Neutral / Reverse
Max. speed M/h(Km/h) 25 (40)
If equipped with standard tires at
maximum engine speed
Brake Hydraulic dry type with caliper disc
Suspension
Front suspension
Independent, MacPherson Strut type
Rear suspension
Independent, Double A-Arm (Wishbone type)
Steering type Rack & pinion
Tire
Front wheel 25 x 10-12 (Worksite)
Rear wheel 25 x 10-12 (Worksite)
Cargo bed
Dimension (L x W x D) in.(mm)
38.6 x 56.2 x 11.5
(980 x 1,427 x 293)
Load capacity lbs(kg) 1,102 (500)
Min. turning radius ft(m) 13.1 (4.0)
Gross Weight lbs(kg) 1,830 (830)
Trailer pulling capacity lbs(kg) 1,300 (590)
Payload capacity lbs(kg) 1,598 (725)
※ Notes: Some option kits are installed as a standard in a certain country.
