1.1 PAPER SPECIFICATIONS
Printer manage thermal roll (heat-sensitive side on outside of roll) or LINERLESS paper (see paragraph
1.1.1).
1.1.1 Specifi cations for LINERLESS paper
LINERLESS paper is a thermal paper with a self-adhesive layer without liner (on non heat-sensitive side). For the
better use with the printer the self-adhesive area must comply with the following dimensions (see fi g. 1.1):
HEAT SENSITIVE SIDE
SELF-ADHESIVE
10 42 5
57 ± 0.5
LINERLESS PAPER SPECIFICATIONS
Self-adhesive Water based acrylic
Self-adhesive mass Permanent 16 gr/m
2
±2gr
Total thickness 93 μm ±2 μm
Total weight 96 gr/m
2
±2gr
Recommended temperature
Stick from +15°C to +40°C
Storage from +10°C to +40°C
Resistance after stick from -10°C to +50°C
(Fig.1.1)
