A.1.4 Data serial cable kit for PLUS II-S-0004
The printer can be supplied with a data serial cable (see fi g.A.11).
PCSKPLUS-0004 Starter kit cables for PCPLUS-S-0004
500mm
X1
Connect the data serial interface cable (1) to the interface connector in the rear of the printer (see fi g.A.12):
.
1
(Fig.A.12)
(Fig.A.11)
APPENDIX A - ACCESSORIES AND SPARE PARTS
User Manual PLUS II A-7
