A.1.2 Adaptor frame kit 112X112
An adaptor frame is available for all the PLUS II models. It makes PLUS II mechanically compatible with CUS-
TOM F and P series panel printers (see fi g. A.3).
PCXSP-PLUS-2 Grey adaptor frame with hooks
PCXSP-PLUS-4 Beige adaptor frame with hooks
The kit is composed of:
Adaptor frame 1.
(1)
N°2 Fixing hooks2.
1
2
2
NOTE:
(1)
Pay attention that the external frame, the cover and the printer frame are made from polypro-
pylene, so it’s better to keep away from: Ammonia, Methanol, Acetone, Washing-up liquid, Benzol,
Dishwasher liquid, Hydrocarbon, Dichloromethane, Perchloretylene, Ethylene, Trichlorethylene,
Toluene.
(Fig.A.3)
APPENDIX A - ACCESSORIES AND SPARE PARTS
User Manual PLUS II A-3
