1.5.2 Setting serial interface
See paragraph 1.4.2.
1.5.3 Power-On confi guration
The JP5 and JP6 jumpers on controller board (see Fig.1.10) manages the setting for the signals of pin 12 and 14
of parallel interface connector as indicated:
SIGNAL OF PIN 12 JP5 SIGNAL OF PIN 14 JP6
FEED GND
ACK LED
Refer to Fig.1.10 for the JP5 and JP6 jumpers position.
JP3
JUMPERS
SELECTION
+VIN ON
PIN 3-4 J3
JUMPERS
SELECTION
INTERFACE
JP4
JP5 JP6
JP1
JP2
TTL CENTRONICS
3
3
3
JP5
P
JP6
6
P
JUMPERS
SELECTION
SIGNAL ON
PIN 12-14
JP5 JP6
FEED
12
ACK
GND
14
LED
(Fig.1.10)
