3.1 TECHNICAL SPECIFICATIONS
Table 3.1 gives the main technical specifi cations for the printer.
Available interfaces
PLUS II-S, PLUS II-S-0004,
PLUS II-T
Serial RS232 / TTL
(Baud rate: from 600 to 38400 bps)
PLUS II-C, PLUS II-C-0004,
PLUS II-P
Parallel Centronics / TTL
PLUS II-USB
Serial RS232
(1)
(Baud rate: from 1200 to 115200 bps)
USB
(2.0 Full speed)
Sensors
Head temperature, paper end
OPTIONAL: Cover open sensor
Printing driver Windows
TM
2K, XP
Receive buffer 128 bytes 2 Kbytes
(2)
Flash memory 32 Kbytes 512 Kbytes
(2)
Emulation ESC/POS PLUS II
(2)
PAPER SPECIFICATIONS
Type of paper
Thermal rolls (heat-sensitive side on outside of roll)
LINERLESS paper (see paragraph 1.1.1)
Label paper roll (see paragraph 1.1.2)
Paper width 57 mm ±0.5 mm
Recommended types of paper from 55 g/m
2
to 70 g/m
2
Internal roll core diameter 13 mm
External roll diameter max. Ø50 mm
Core type Cardboard or plastic
ENVIRONMENTAL CONDITIONS
Operating temperature 0-50°C
Relative humidity 10-85% Rh
Storage temperature /
Humidity
-20 °C – 70 °C / 10% - 90% Rh
MECHANICAL SPECIFICATIONS
Dimensions
Length [mm] = 85 max.
Width [mm] = 57 max.
Height [mm] = 85.5 max
Weight [gr] 141
(3)
NOTE
(1)
RESERVED interface, only for service use.
(2)
Only for PLUS II-USB.
(3)
Referred without paper roll.
(Tab.3.1)
