Custom Engineering PLUS II - Printing Specifications (Non-USB Models); Printing Specifications (USB Model)

Table 3.2 gives the printing specifi cations for the PLUS II-S, PLUS II-S-0004, PLUS II-T, PLUS II-C, PLUS
II-C-0004, PLUS II-P.
PRINTER SPECIFICATIONS
Print method Thermal, fi xed head
Resolution 204 DPI (8 dot/mm)
Printing mode Straight, 180°
Printing format Normal, width from 1 to 2, bold, reverse, underlined
Character fonts ASCII standard, international
Graphics memory 1 Logo (384 x 85 dots)
Number of columns 24 40
Character matrix 16 X 24 8 X 24
Printing speed
Lines /sec. 13 13
Chars / sec. 307 512
Characters (L x H mm) 2 x 3 1 x 3
Table 3.3 gives the printing specifi cations for the PLUS II-USB.
PRINTER SPECIFICATIONS
Print method Thermal, fi xed head
Resolution 204 DPI (8 dot/mm)
Printing mode Straight, 90°, 180°, 270°
Printing format Height/width from 1 to 8, expanded, negative, underlined, italic
Character fonts PC837, PC850, PC860, PC863, PC865, PC858 (euro)
Graphics memory 4 Logo (384 x 680 dots)
Number of columns 24 32 40 42
Character matrix 16 x 24 12 x 24 9 x 24
Character density 12 cpi 17 cpi 22 cpi
Characters (L x H mm) 2 x 3 1,5 x 3 1,1 x 3
Printing speed Up to 50 mm/sec
(Tab.3.2)
(Tab.3.3)
3. TECHNICAL SPECIFICATIONS
3-2 PLUS II User Manual
