A.1.5 Data and power supply cables kit for PLUS II-C and PLUS II-P
The printer can be supplied with a data and power supply cables starter kit.
PCSKPLUS-C Starter kit cables for serial PCPLUS-C and PCPLUS-P
The kit includes (see fi g.A.13):
Power supply cable.1.
Data cable for parallel interface.2.
500mm
1
2
To connect the cable proceed as follows (see fi g.A.14):
Connect the power supply cable (1) to the power supply connector in the rear of the printer;•
Connect the data parallel interface cable (2) to the interface connector in the rear of the printer.•
1 2
(Fig.A.14)
(Fig.A.13)
