A.1.6 Data parallel cable kit for PLUS II-C-0004
The printer can be supplied with a data parallel cable (see fi g.A.15).
PCSKPLUS-C-0004 Starter kit cables for PCPLUS-C-0004
500mm
1
Connect the data parallel interface cable (1) to the interface connector in the rear of the printer (see fi g.A.16):
1
(Fig.A.16)
(Fig.A.15)
APPENDIX A - ACCESSORIES AND SPARE PARTS
User Manual PLUS II A-9
