Custom Engineering PLUS II - Electrical Specifications (Non-USB Models); Electrical Specifications (USB Model)

Table 3.4 gives the electrical specifi cations for the PLUS II-S, PLUS II-S-0004, PLUS II-T, PLUS II-C, PLUS
II-C-0004, PLUS II-P.
ELECTRICAL CONDITIONS
Power Supply Vcc Vin
PLUS II-S, PLUS II-T 3.5 ÷ 8 V (Range max.) 3.5 ÷ 8 V (Range max.)
PLUS II-S-0004 - 9 ÷ 48 V (Range max.)
PLUS II-C, PLUS II-P 5 ± 5% 3.5 ÷ 8 V (Range max.)
PLUS II-C-0004 - 9 ÷ 48 V (Range max.)
Absorptions (5 V)
Medium
(50% dot ON) 0.2 A (Vcc) 3.3 A (Vin)
Stand by 0.1 A
Absorptions (9 ÷ 48 V)
Medium
(50% dot ON) 3 A (9 V) 0.7 A (48 V)
Stand by 0.1 A
Absorptions (3.5 ÷ 8 V)
Medium (50% dot ON) 3.3 A (3.5 V) 2.5 A (8 V)
Stand by 0.1 A
Table 3.5 gives the electrical specifi cations for the PLUS II-USB.
ELECTRICAL CONDITIONS
Power Supply 10 ÷ 32 V
Absorptions (10 V)
Medium (50% dot ON) 2.5 A
Stand by 0.1 A
Absorptions (32 V)
Medium
(50% dot ON) 0.8 A
Stand by 0.1 A
General note:
Codes description:
Code Interfaces
PLUS II-S Serial RS232
PLUS II-S-0004 Serial RS232 Extended range
PLUS II-T Serial TTL
PLUS II-C Parallel Centronics
PLUS II-C-0004 Parallel Centronics Extended range
PLUS II-P Parallel TTL
PLUS II-USB USB - Serial RS232
(Tab.3.4)
(Tab.3.5)
