Custom Engineering PLUS II - PLUS II Rear View Connectivity

B. PLUS II - Rear view
1 - Power supply connector
2 - RS232 / TTL serial interface connector
3 - CENTRONICS / TTL parallel interface connector
4 - USB interface connector
5 - RS232 serial interface connector
(1)
1 2 1 2
PLUS II-S / PLUS II-T PLUS II-S-0004
1 3 1 3
PLUS II-C / PLUS II-P PLUS II-C-0004
(Fig.3) (Fig.4)
(Fig.5) (Fig.6)
PLUS II User Manual
