C. PLUS II - Internal view
1 - Printing head
2 - Rubbed roller
3 - Seat for fi xing hook (provided in the package)
4 - Paper presence sensor
5 - Cover open sensor (optional)
4
5
3
1
2
NOTE : The description of the internal components is valid for all the PLUS II models.
(Fig.8)
