Remove crank covers
1. Remove both screws securing crank cover using a Phillips screwdriver.
Qty.DescriptionItem
2Screw1
1Crank cover2
1Crank arm3
1Flush mount4
1Crank shaft5
2. Remove crank cover.
3. Repeat steps for other crank cover.
Remove shrouds
1. Remove seven screws securing left shroud in place using a long Phillips screwdriver.
Qty.DescriptionItem
7Screw1
1Left shroud2
2. Remove three screws securing right shroud in place using a long Phillips screwdriver.
3. Remove both shrouds.
Page 118 of 202
Cybex 772A, 772AT Arc Trainer Part Number
