Remove Accessory Tray Bottom
1. Remove the three screws securing the accessory tray bottom to the accessory tray base using a
Phillips screwdriver.
Qty.DescriptionItem
1Accessory Tray Bottom1
1Accessory Tray Top2
2
Screw, Pan Head Phillips, 6 x
.50"
3
1
Screw, Pan Head Phillips, 8-
16 x .50"
4
2. Remove the accessory tray bottom
Remove Accessory Tray Top
Remove the two screws securing the accessory tray top to the accessory tray base using a stubby
Phillips screwdriver.
Qty.DescriptionItem
1Accessory Tray Top1
1Accessory Tray Base2
2
Screw, Pan Head Phillips, 8-
16 x .50"
3
Remove Accessory Tray Base
Remove the four screws securing the accessory tray base to the frame using a stubby Phillips screwdriver.
