Qty.DescriptionItem
1Book Tabs1
1Bezel2
2Screw3
Install book tabs
Install the two screws securing the book tabs to the new bezel using a Phillips screwdriver.
Qty.DescriptionItem
1Book Tabs1
1Bezel2
2Screw3
Install CardioTouch screen
1. Place the new CardioTouch screen in place in the bezel.
Qty.DescriptionItem
1Bezel1
1CardioTouch screen2
1Clip3
7Screw4
2. Install seven screws and clip, tighten by hand.
Page 181 of 202
Cybex 772A, 772AT Arc Trainer Part Number
