CYBEX Arc Trainer 772A User Manual

3. Unplug optional iPod cable.
The iPod cable is held in place by a notch in the access cover.
a) Press in both side latches of cable connector.
b) Ensure latches disengage from the connector.
c) Unplug cable by holding down latches on both sides and pulling straight out from connector.
Do not pull on wires, remove by connector.
Remove Cybex GO monitor cables
1. Unplug the power, ethernet cable, and control board cable from the Cybex GO monitor.
Qty.DescriptionItem
1Power cable1
1Cat6 ethernet cable2
1Coax cable3
1Control board cable4
2. Unscrew the coax cable from the Cybex GO monitor.
3. Remove the ground cable from the Cybex GO monitor using an 11/32” nut driver.
Page 194 of 202
Cybex 772A, 772AT Arc Trainer Part Number
