The Load Leg is an effective safety feature of the Aton Q and
using it is STRONGLY RECOMMENDED. However, if necessary
(e.g. in a center position with a hump in the oor), the Base may
be installed with the Load Leg folded up underneath the Base. If
ALL installation requirements for the Load Leg cannot be met,
you MUST choose another seating position, or install the Infant
Carrier without the Base.
TO EXTEND
1. Install the Base making sure Recline Angle is
correct for your child. See page 28.
2. Squeeze the Adjustment Handle on the Load Leg and
extend the Foot until it rests on the vehicle oor.
3. Secure the Foot into place using the rst hole that will lock it rmly
against the vehicle oor without lifting the Base up off of the seat.
It may be necessary to lift up slightly on the Base to allow the Foot to
lock into the hole.
TO RETRACT
Squeeze Handle and push up on the foot to retract.
27
Use the FIRST
hole that will lock
the Load Leg Foot
rmly against
vehicle oor
There should NEVER be
any space between the
Load Leg Foot and the
vehicle oor.
The Load Leg should
NEVER push the Base
above the vehicle seat.
2
1
When possible, INSTALL the Aton Q Base in a seating
position that will allow the Load Leg to be extended
into a locked position with rm contact with the
vehicle oor.
NEVER INSTALL the Aton Q Base in a seating position
where the Load Leg, even in its shortest position,
causes the Base to be pushed up above the vehicle
seat. If necessary, the Base may be installed with the
Load Leg folded up underneath the Base.
NEVER EXTEND the Load Leg Foot beyond the FIRST
hole that will lock it rmly against the vehicle oor.
USING THE LOAD LEG
