CYBEX ATON Q User Manual

SECURING THE CHILD
1. Loosen Harness by rmly pressing down the
Harness Adjustment Button
a
while pulling
forward on both straps at shoulder level.
b
2. Press red button on Harness Buckle to release Tongues.
3. Separate Chest Clip and spread straps apart. Place child
in Infant Carrier in seated position making sure their
bottom is in the seat, and their back is fully supported.
4. Pull Harness straps over each arm onto shoulders
and around the hips. Make sure Buckle Pad and
Harness Buckle are between the legs.
Newborns tend to draw arms and legs close to their bodies. Gently extend
each limb to allow for proper Harness positioning. Be mindful of especially
sensitive areas (e.g. bellybuttons, circumcisions).
5. Buckle by inserting one Tongue at a time into the
Harness Buckle listening for an audible CLICK with each
one. Make sure Harness Straps are not twisted.
6. Connect the Chest Clip listening for an audible CLICK.
20
CLICK!
CLICK!
CLICK!
2
3
4
5
1
6
a
b
MAKE SURE Harness straps are AT or BELOW child's
shoulders. If not, refer to page 19.
ALWAYS check Harness Buckle to make sure it is
securely latched. Failure to fasten and tighten the
Harness system correctly with each use can result in
DEATH or serious injury.
USING THE INFANT CARRIER
EN

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
