CYBEX ATON Q User Manual

It is very important for your child's safety that this child
restraint be installed at the correct recline angle. Before
attaching the Infant Carrier to the Base, always check the Level
Indicator for the correct recline angle range based on your
child's weight.
Vehicle must be on a level surface for the Level Indicator to function
correctly.
ADJUST RECLINE ANGLE
1. Squeeze the Level Adjustment Handle to extend or retract
the Leveling Foot until the Base is within the recommended
range for your child. There are four recline positions.
2. Release handle to lock Foot in place.
3. Install Base. Be sure to check for correct
recline angle after installation.
If the Recline Angle is not correct after installation, uninstall the base,
adjust Leveling Foot and reinstall.
28
DO NOT use this or any other child restraint with a
premature, low birth weight, or medically fragile infant,
until after you have consulted with your doctor. Some
infants may have difculty breathing or have other
medical problems when placed in a seated position.
If the child restraint is too upright, the child's head
may fall forward and cause breathing problems. If the
child restraint is TOO RECLINED crash protection will
be reduced.
Failure to properly recline the child restraint on the
vehicle seat increases the risk of Death or serious
injury.
ADJUSTING THE RECLINE ANGLE USING THE BASE
EN

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
