CYBEX ATON Q User Manual

8. Press the Belt Tensioning Plate down with both hands, where
indicated, until it locks into place. The orange Locking Lever
will rotate to the
CLOSE position when the Plate is locked.
If Belt Tensioning Plate does not lock, try loosening the LATCH strap
slightly.
9. Grab the Base at the Belt Guides and pull from side to side
and front to back to make sure it is installed correctly. The base
should not move more than 1 inch (2.5 cm) in any direction.
If the Base moves too much, open the Belt Tensioning Plate, tension
the LATCH Strap a little more and try again. After this, if the Base still
moves too much, you may need to try a different vehicle seat location
or installation method, or both.
10. Squeeze the Adjustment Handle on the Load Leg
and extend it until the Foot makes rm contact with
vehicle oor. Lock Leg into place using the rst hole
that will rmly lock it against the vehicle oor.
It may be necessary to lift up slightly on the Base to allow the Foot to
lock into the hole. See page 27.
11. Check that the Recline Angle remained in the appropriate
range for the child's weight. If not, remove Base,
adjust recline angle and reinstall. See page 28.
30
Use the FIRST hole
that will lock the Load
Leg Foot rmly against
vehicle oor
8
9
10
11
INSTALLING THE BASE USING LATCH
EN

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
