CYBEX ATON Q User Manual

ATTACHING INFANT CARRIER TO BASE
1. Make sure handle is LOCKED in the DRIVE/CARRY position.
2. Lift Infant Carrier by the Handle and slide the Attachment
Rod under the Attachment Catch on the Base.
3. Rotate foot end of the Infant Carrier down onto
the Base until an audible CLICK is heard.
The green Safety Button will pop out from the middle of the Infant
Carrier Release to indicate proper attachment.
The Aton Q is allowed to touch the vehicle seat(s) in front of it, as
long as the recline angle of the Aton Q is not affected.
RELEASING INFANT CARRIER FROM BASE
If used, retract the L.S.P. device. See page 43.
1. Press the green Safety Button
a
in while pushing
the Infant Carrier Release down
b
.
2. Slightly tilt Infant Carrier toward front of vehicle.
Grasp Infant Carrier with both hands to lift off.
35
a
b
2
3
2
1
1
ALWAYS have the handle locked in the upright DRIVE/
CARRY position while using this child restraint in a
vehicle.
ALWAYS verify that the handle is LOCKED in the Carry
position before lifting Infant Carrier by the handle. An
unlocked handle could move unexpectedly, causing
child to fall out.
USING THE INFANT CARRIER WITH THE BASE

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
