CYBEX ATON Q User Manual

8. Press the Belt Tensioning Plate down with both hands where
indicated, until it locks into place. The orange Locking Lever will
rotate to the
CLOSE position when the Plate is locked.
If Belt Tensioning Plate does not lock, try loosening the vehicle belt slightly.
9. Grab the Base at the Belt Guides and pull from side to side and
front to back to make sure it is installed correctly. The Base should
not move more than 1 inch (2.5 cm) in any direction.
If the Base moves too much, open the Belt Tensioning Plate and remove a little more
slack from the vehicle belt, close Plate and recheck. After this, if the Base still moves
too much, you may need to try a different vehicle seat location or installation method,
or both.
10. Squeeze the Adjustment Handle on the Load Leg and extend it until
the Foot makes rm contact with vehicle oor. Lock Leg into place
using the rst hole that will rmly lock it against the vehicle oor.
It may be necessary to lift up slightly on the Base to allow the Foot to lock into the hole.
See page 27.
11. Check that the Recline Angle remained in the appropriate range for the child's
weight. If not, remove Base, adjust recline angle and reinstall. See page 28.
Make sure that vehicle belt buckle and hardware do not interfere with correct
installation of the Base, or with the connection of the Infant Carrier to the Base.
12. Put vehicle belt in LOCKED mode, see vehicle
Owner's Manual
for more information.
In most vehicles, you can switch the shoulder belt retractor into locking mode by pulling out
shoulder belt all the way and then letting it rewind into the retractor. Pull on the belt to make
sure it is locking.
32
Use the
FIRST hole
that will lock
the Load
Leg Foot
rmly against
vehicle oor
10
8
9
11
12
NEVER install this child restraint using a non-locking vehicle lap
shoulder belt. A locking clip must be used with a vehicle belt that
DOES NOT LOCK. Call the Regal Lager Customer Care Department at
1.800.593.5522 to obtain a locking clip.
INSTALLING THE BASE USING A LAP AND SHOULDER BELT
EN

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
