CYBEX ATON Q User Manual

The FAA recommends that children up to 40 pounds
(18 kg) use a certied, harnessed child seat while travelling
on an airplane. The Aton Q is certied for airplane use.
INSTALLING THE CARRIER ON AIRPLANE
Install your Infant Carrier in a window seat to avoid blocking the
aisle.
1. Position Infant Carrier rear facing in aircraft seat with the
foot end rmly against the back of the vehicle seat.
2. Route lap belt under both Belt Guides. BUCKLE THE BELT.
3. Push Infant Carrier rmly into aircraft seat
while removing slack from the lap belt.
4. Check the recline angle. Adjust the seat angle until the red
Level Line on the Infant Carrier is level with the oor of the
aircraft. A tightly rolled airline blanket may be placed under
the Infant Carrier to adjust the angle. See page 42.
5. Grab the Infant Carrier at the Belt Guides and pull
from side to side and front to back to make sure it
is installed correctly. The Infant Carrier should not
move more than 1 inch (2.5 cm) in any direction.
If the Infant Carrier moves too much, tighten the airplane belts more
and recheck.
41
1
3
4
2
LINE MUST BE LEVEL WITH GROUND
WHEN INSTALLED WITHOUT BASE
FRONT OF VEHICLE
LINE MUST BE LEVEL WITH GROUND
WHEN INSTALLED WITHOUT BASE
FRONT OF VEHICLE
CLICK!
DO NOT USE the Base on airplane.
ALWAYS have the handle locked in the upright DRIVE/
CARRY position while using this child restraint on
aircraft.
NEVER use the L.S.P. device on airplane.
USING THE INFANT CARRIER ON AIRPLANE

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
