3. The DIVE Gauge
Features of the DIVE Gauge
Left Side View showing Button, Battery
& Probe Connector with Cap Fitted
Right Side View showing Button,
Battery Retaining Screw & Probe
Connector
Fitting the DIVE Gauge
The DIVE gauge can be worn on the fore-arm of the diver allowing
one hand to remain free during thickness surveys. The gauge is
secured with a tough elasticated strap with a quick release buckle,
the strap can be tightened easily using one hand and being
elasticated it will maintain its grip on the diver’s dry suit.
Probe
Connector
(Cap Fitted)
Left
Button
Battery
Probe
Connector
Right
Button
Colour
Display
Battery
Screw
