Menu Tree Diagram
The menu tree diagram shows the gauge’s menu items in the
order they are displayed. Note some of the items are only
displayed if that feature is enabled.
Measurement Screen
Displayed when;
Main Menu
DATA LOG MENU
START LOGGING
Data Logging Stopped
CLEAR MEMORY
DATA LOGGER STATUS
DELETE LAST
Data Logging Started
STOP LOGGING
START NEW GROUP
CLEAR MEMORY
DATA LOGGER STATUS
DEEP COAT
Multiple Echo Mode
MEASURE MODE
SE/EE Mode
A-SCAN RANGE
A-SCAN DISPLAY
Multiple Echo Mode
VELOCITY
Or
Not Measuring
CALIBRATE
Measuring
CALIBRATE 2 POINT
SE/EE Mode
MATERIAL LIST
ZERO PROBE
SE/EE Mode
UNITS
RESOLUTION
PROBE TYPE
SETUP MENU
POWER-SAVE TIMER
DLOG RELEASE TIME
