Page 80 of 117
Connection Diagram
Connector Details and Signals
See Connection s from page 113
Using CygLink with HelmetView
As HelmetView and CygLink both need to connect to the spare
connector on the gauge a “Y” splitter cable is required. For the
part number see Accessories on page 102.
