The Measurement Screen
When the gauge is operating the measurement screen is
displayed.
No Probe Connected Message
When the probe is disconnected from the
gauge a NO PROBE message is displayed.
Measurement
Units
Velocity of
Sound
Echo Bars
or
Thickness
Measurement
Value
A-Scan
Display
Battery
Level
Probe
Type
Measure
Mode
Signal
Strength
