Section 4 - Conguration
Button Button Name Function
Prole Buttons
Use these buttons to switch between video
proles. Refer to “Audio and Video” on page
43 for information on setting up proles.
Full Screen Button Click to display the video at full screen.
Snapshot Button
Click to take a snapshot of the image currently
displayed on the screen and save it to a le on
the hard drive in a folder specied using the
Storage Folder button.
Video Recording Button
Click to trigger the camera’s recording function.
This will record the video displayed on the
screen and will save it to a le on the hard drive
in a folder specied using the Storage Folder
button.
Storage Folder Button
Click to select a Storage Folder for saving
snapshots and video recordings to.
Listen Button
Click to send the audio received from the
camera’s microphone to the PC’s speakers. Click
again to stop audio in.
Talk Button
Click to end audio from a microphone connected
to your PC to the speakers connected to the
camera. Click again to stop audio out.
Start/Stop Digital Output
Press this button to start and stop digital
output.
Below is a description of the buttons that appear across the bottom of the Live Video screen.
