Master Hub Setup and Management 57
♦ Group ID
. This field indicates which hub is being displayed.
♦ Group Serial Number
. Displays the hub factory assigned serial
number.
♦ Group Position Number
. Displays the hub stack position relative
to the other hubs (1 is the highest in the stack, 5 the lowest).
♦ Group Description
. This field gives a description of the given hub,
showing its model number.
♦ Group Role
. Shows what role the hub is currently playing in the hub
stack (primary master, standby master, or slave).
♦ Group Port Capacity
. This field shows the total number of network
ports on the hub.
Note: When modules with additional ports are in-
stalled in DFE-2600 series hubs, the Port
Capacity number will automatically adjust to
reflect the added ports. The management
software does not discriminate, any type of
added or removed port will change the Port
Capacity number.
♦ Group Hardware Revision
. This field shows the design version of
the hub hardware.
♦ Group Master Revision
. Displays the design version for master
hubs.
♦ Group Status
. This field shows whether the hub is up-and-running or
down.
♦ Group Last Oper Change
. This field shows the time when the hub
was last added to or removed from the stack. The format is
To Next Page
