D-Link DNS-313 User Manual

8D-Link DNS-313 User Manual
Section 2 - Installation
3. Insert a 3.5” SATA hard drive into the drive bay.
Make sure to align the drive connector to the SATA
connectors on the bottom edge inside the drive bay of
the DNS-313. Gently push the drive in until it connects.
When a drive is inserted properly, you will feel it “seat”
into the connector. Some hard drives that are thin or
oddly shaped may need to be guided carefully into
position. If the drive is not properly seated, the Drive
LED will not illuminate after powering on the device.
4. Attach the faceplate to the front of the device.

D-Link DNS-313 Specifications

Device Interfaces

Gigabit Ethernet port	1 10/100/1000
USB port	1 USB 2.0
Power socket	external power adapter

Operating Environment

Operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
Storage temperature	-20˚ to 70˚ C (-4˚ to 158˚ F)
Operating humidity	5% to 90% (non-condensing)

Weight and Dimensions

Dimensions	200 (L) x 124 (H) x 49 (W) mm
Weight	1.29 Kg
Supported hard drive type	3.5-inch internal SATA
