Internet/Print Server User’s Guide
Configuration Settings44
ISP Account -> IP Address
Options: The IP address the ISP has assigned to this ac-
count.
Default Value: 0.0.0.0
Description: Dial-up connections should use address 0.0.0.0
if the IP will be dynamically assigned at each connection.
Otherwise, enter the IP address assigned by your ISP.
Modem AT Commands
Options (sub-settings):
♦ Init. String: <AT&F> (default)
♦ Dial Prefix String: <ATDT> (default)
♦ Hangup String: <~~~+++~~~ATH0> (default)
Description: Modem AT commands are used to configure
and operate the modem when it is necessary to control settings
such as the speaker volume, line modulation, or handshaking
protocol.
Note: See your modem user’s guide for informa-
tion about initialization string settings and
other modem commands.
Note that the initialization string modem command must set the
following:
1. Fixed baud rate (i.e., serial data rate adjustment dis-
abled).
