Specifications 65
B
SPECIFICATIONS
General
Standards: IEEE 802.3 10BASE-T Ethernet repeater, IEEE 802.3u
100BASE-TX Fast Ethernet repeater (Class II); ANSI X3T9.5
Twisted-Pair Transceiver; IEEE 1284 bi-directional parallel interface
Protocol: CSMA/CD
Network Data Transfer Rate: NWay – Fast Ethernet, 100Mbps;
Or Ethernet,10Mbps
Ports: One RJ-45 NWay LAN port; One RS-232 serial WAN port;
and One 25-pin standard parallel printer port
Network Media: Ethernet: Category 3 or better UTP cable, 100m
maximum; Fast Ethernet: UTP Cat 5 or STP, 100-ohm twisted-pair
100m maximum.
Status LEDs: Pw/Tx (power on/transmit); Link/Rx (connect
o.k./receive); LPT and COM.
