6D-Link DSL-2745 Wireless N300 ADSL2+ Modem Router User Manual
Section 1 - Product Overview
Hardware Overview
Back
1 Reset Button
To reset the DSL-2745 to the default settings, insert a paperclip into the hole on the bottom of the device
located near the label and wait several seconds.
2 DSL Port Connects to an DSL-enabled telephone line.
3 LAN Ports (1-4) Connects Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
4 WPS Button Press to start the WPS process and automatically create a secure connection to a WPS client.
5 Wireless On/O Press and hold this button for about 5 seconds to enable or disable the Wi-Fi network.
6 Power Button Press to power the DSL-2745 on or o.
7 Power Connector Connector for the supplied power adapter.
3 6 74 521
