D-Link DSL-2745 User Manual

113D-Link DSL-2745 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Access Control List IPv6
This page allows you to enable or disable various services from being used on
the LAN or WAN side using IPv6 parameters.
Direction Select: Choose either LAN or WAN.
ACLV6 CONFIGURATION  DIRECTION
LAN ACL Switch: Choose either Enable or Disable.
LAN ACL SWITCH CONFIGURATION
IP Address: Enter the IPv6 IP address and prefix.
Services Allowed: Un-check Any to individually select the services which will be
available on your LAN.
ACLV6 SETTINGS
The following settings are available if Direction Select is set to LAN:
Click Add to add the ACLv6 rule.
