D-Link DSL-2745 User Manual

114D-Link DSL-2745 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Access Control List IPv6 (continued)
The following settings are available if Direction Select is set to WAN:
The following settings are available if WAN Setting is set to Interface:
WAN Setting: Select either Interface or Address.
ACLV6 SETTINGS
Click Add to add the ACLv6 rule.
WAN Interface: Select the WAN interface to apply the ACLv6 rule to.
Services Allowed: Select the services to allow.
The following settings are available if WAN Setting is set to IP Address:
IP Address: Enter the IPv6 IP address and prefix.
Services Allowed: Select the services to allow.
CURRENT IPV6 ACL TABLE
This table displays the IPv6 ACL rules. To delete a rule, click Delete.

D-Link DSL-2745 Specifications

General

Brand	D-Link
Model	DSL-2745
Category	Network Router
Language	English
