72D-Link DSL-2745 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Port Forwarding
Port Forwarding allows you to direct incoming trac from the WAN side
(identied by Protocol and WAN port) to an internal server with a private IP
address on the LAN side.
Well known
Service:
Commonly used protocols are pre-defined and can be easily
selected.
User-defined
Service:
Name the rule you are about to define for your server.
Protocol: Select the protocol type to use with this service.
WAN Port: Enter the WAN port number.
LAN Port: Enter the LAN port number.
LAN IP Address: Enter the IP address trac is forwarded to.
PORT FORWARDING SETUP
Click Add to add the new port forwarding rule. To modify an existing rule,
select it using the radio selection button. The boxes of the Port Forwarding
Setup section will populate with the rules parameters. Enter your changes and
click Modify.
