Section 7 - VPN
5. The elds to be lled-in on the conguration page are given below.
Field Description
Source IP Range Start
Enter an IP address from the private (LAN) IP subnet which will be the starting IP address for One To One
mapping rule.
Mapped IP Range Start
Enter an IP address, which acts as starting IP of mapped range of One To One mapped subnet to private
LAN IP subnet . This IP is used to map the trac from remote host to a local LAN host/subnet of LAN
hosts . This IP should be same as ‘Local Start IP Address’ in IPSec policy of local Device and ‘Remote Start
IP Address’ in IPSec policy of remote device.
Range Length
Enter a value between 1 to 254. This value indicates the number of private LAN IP addresses in LAN
subnet which would be One To One map with mapped IP subnet range.
IPSec Policy Name
Select an IPSec policy from the drop down list in order to associate IPSec policy with conguring One To
One Mapping rule.
Save Click it to save your settings.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
