D-Link DSR-Series User Manual 211
Section 8 - Security
License Update
Path: Maintenance > Administration > License Update
Certain features can be added to the router by purchasing a license key. An activation code is provided based on
the router’s MAC Address, so it will be unique to that particular device.
Field Description
Free WCF Trial for 90 Days
Click Enable Free Trial. You can use dynamic ltering feature free for 90 days. This option can be
used for once only.
Licenses List
License Model It displays the license model as it relates to the feature being added.
Activation Code It displays the activation code corresponding to this license.
Expires
It displays the date of expiration. Licenses can either have a xed duration, or are perpetual for
the life of this router.
Activation Setup
License Activation Code Enter the new activation code to activate the license.
Activate Click Activate to activate the entered license activation code.
The license update page displays the elds given in the table below:

Table of Contents

Other manuals for D-Link DSR-150

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DSR-150 and is the answer not in the manual?

D-Link DSR-150 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet interface typeFast Ethernet
PC in (D-Sub)No
USB ports quantity0
Ethernet LAN (RJ-45) ports8
Supported network protocolsIPSec, PPTP, L2TP
Security algorithms3DES, DES, SSL/TLS
VPN tunnels quantity21
Filtering descriptionKeyword
MAC address filtering-
SafetycUL, LVD (EN60950-1)
CertificationWEEE
Electromagnetic compatibilityFCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)240000 h
Input current1.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)7.44 W
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Product colorBlack
Input voltage12 V
Ports quantityThe number of ports or external interfaces to which other equipment can be connected.
Management platformHTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technologyWired
Compliance industry standardsRoHS
Weight and Dimensions IconWeight and Dimensions
Depth118 mm
Width208 mm
Height35 mm
Weight- g
