Path: Network > Internet > Trac Management > Trac Shaping
Once a prole has been created it can then be associated with a trac ow from the LAN to WAN. Trac selector
conguration binds a bandwidth prole to a type or source of LAN trac with the following settings.
To create a trac selector:
1. Click Network > Internet > Trac Management > Trac Shaping.
Trac Shaping
2. Click Add New Trac Selector.
Field Description
Available Proles Select a bandwidth prole from the drop-down menu.
Service Select a service from the drop-down menu.
Trac Selector Match
Type
Select any one of the following match types:
• IP: Select this option to associate this trac selector to an IP Address of a LAN device. Once selected,
enter the IP address of the LAN device.
• MAC Address: Select this option to associate this trac selector a specic MAC address on the
LAN. Once selected, enter a valid MAC Address.
• Port Name: If this option is selected, enter the LAN port number (1 through 4).
• VLAN: Select this option to associate this trac selector a specic VLAN. If this option is selected,
select one of the congured Port Name identiers.
IP Address If you select IP, enter the IP address of the source associated with this prole.
3. Complete the elds from the table below and click Save.
