D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 128
Section 7 - VPN
4. Complete the elds from the table below and click Save.
Field Description
Policy Type Select Global, Group, or User.
Available Groups/Users
If you selected Group, select a group from the drop-down menu. If you selected User, select a
user from the drop-down menu.
Apply Policy To Select Network Resource, IP Address, IP Network, or All Addresses.
Policy Name Enter a unique name for this policy.
IP Address If you selected IP Address or IP Network, enter the IP address.
Mask Length If you selected IP Network, enter the mask length (0-32).
ICMP Toggle to ON to include ICMP trac.
Begin/End
Enter a port range or leave blank to include all TCP and UDP ports. These elds are not available
when selecting Network Resource.
Dened Resources
If you selected Network Resource, select the resource for the Dened Resource drop-down
menu. If you have not created a resource, refer to “Resources” on page 131 to create a dened
resource.
Service
Select either VPN Tunnel, Port Forwarding, or All. This eld is not available when selecting
Network Resource.
Permission Select either Permit or Deny.
Save Click to save your settings.
Network Resource IP Address

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
