D-Link DSR-Series User Manual 67
Section 5 - Connect to the Internet
Field Description
Prole Name Enter the name of the prole to be congured for a particular Source Type.
Source Type Select a source type for the prole.
IP Address
Congure the IP Address of the client/Host to be controlled in the Session Limit prole when the selected
prole type is IP.
Start IP Address
Congure the Start IP Address of the clients to be controlled in the Session Limit prole when the
selected prole type is Range.
End IP Address
Congure the End IP Address of the clients to be controlled in the Session Limit prole when the selected
prole type is Range.
Interface
Select the Interface from the drop down list to select the complete network to be controlled in the
Session Limit prole when the selected prole type is Interface.
Maximum Sessions
Congure the Maximum sessions from the Range 1-999 that are allowed on Source Type to limit sessions.
Once the limit is reached, it will not allow any type of sessions/trac on Session Limit prole.
Enable Schedules Enable Schedules to add the session limit prole with schedule congured for a day/all days.
Schedule Prole Select Schedule Prole to associate to the session limit prole.
Save Click save and activate your settings.
3. Complete the elds from the table below and click Save.
