D-Link DSR-250N - Firewall Rule Configuration Examples; Figure 60: List of Available Ipv6 Firewall Rules

Unified Services Router User Manual
90
Figure 60: List of Available IPv6 Firewall Rules
5.4.1 Firewall Rule Configuration Examples
Example 1: Allow inbound HTTP traffic to the DMZ
Situation: You host a public web server on your local DMZ network. You want to
allow inbound HTTP requests from any outside IP address to the IP address of your
web server at any time of day.
Solution: Create an inbound rule as follows.
Parameter
Value
From Zone
Insecure (WAN1/WAN2/WAN3)
To Zone
Public (DMZ)
Service HTTP
Action
ALLOW always
Send to Local Server (DNAT IP)
192.168.5.2 (web server IP address)
Destination Users
Any
Log
Never
Example 2: Allow videoconferencing from range of outside IP addresses
