D-Link DWM-312W

6D-Link DWM-312W User Manual
Section 1 - Product Overview
DIN Mounting / SMA Connectors
1 SMA Connector AUX SMA female connector - auxiliary antenna.
2 SMA Connector MAIN SMA female connector - primary antenna.
3 SMA Connector WIFI SMA male connector - Wi-Fi antenna.
4 DIN Mounting Unit The mounting unit used to x the DWM-312W in place.
1
2
3 4
