D-Link GO-RT-N300 User Manual

15D-Link GO-RT-N300 User Manual
Section 3 - Conguration
You can also configure the wireless network and security
settings. If you prefer not to, click Disable the wireless radio.
Click Next to continue.
If you selected Static IP, enter your IP address, Subnet Mask,
Default Gateway, Primary DNS, and Secondary DNS, and click
Next to continue.
Enter the SSID name.
Use the dropdown menu to select the wireless channel.
Use the dropdown menu to specify the wireless mode
Use the dropdown menu to select the channel bandwidth.
If you selected the 802.11n, 802.11 b/g, or 802.11 b/g/n
wireless modes, the available options are 20 MHz and
20/40MHz. For the others, 20MHz is the only option.
You can also choose to not use security by selecting this,
but this is not recommended.
If you select this, enter a passkey in the box below the field.
SSID:
Channel:
Mode:
Channel Width:
Disable
Security:
WPA/WPA2-
Personal:
GO-RT-N300

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
