D-Link mydlink DNR-202L

51D-Link DNR-202L User Manual
Section 5: Conguration
Audio and Video
Step 1:
Select the camera which you would like to modify from the camera list.
Step 2:
NVR will display the parameters for the selected camera. You can modify the information
on this page.
Name:
Video Format:
Frame rate:
Resolution:
Quality:
Audio:
Go to Web:
The Name of the camera.
Select the Video Format the camera supports.
Select the Frame Rate of the camera.
Select the Resolution of the camera.
Select a Constant bit rate and Fixed quality for the image.
Check the Enable Audio option to enable audio recording.
Click on the link to the right of the Model name to connect to the web
page for the selected network camera for advanced setup. For example,
motion detection should be congured via the camera web interface to
enable the NVR to receive the trigger message.
Step 3:
Click the Save Setting button.
Note: The system will adjust the frame rate automatically based on the maximum frame rate which that camera can support.
This section will allow you to congure and modify the audio and video parameters for each camera.
