D-Link mydlink DNR-202L

64D-Link DNR-202L User Manual
Appendix A - LED and Alarm Overview
LED and Alarm Overview
LED Color Status Description
Power & Network
LED
Red On Powered, Not Connected to the Network
Device Initialization (Boot Process)
Blinking Firmware Update
Blue On Powered, Connected to the Network
Blinking Network Trac
O O O
USB1 LED Green On HDD Connection is Active
Blinking USB Read / Write Activity
O Safe to Disconnect USB Drive
USB2 LED Green On HDD Connection is Active
Blinking USB Read/Write Activity
O Safe to Disconnect USB Drive
Key Trigger Method Description
USB1 button Press button for 3 seconds Un-mount HDD1, Buzzer will beep (long).
USB1 LED o.
USB2 button Press buttonfor 3 seconds Un-mount HDD2, Buzzer will beep (long).
USB2 LED o.
Auto Scan
button
Auto Scan function- Press scan button for 3 seconds Start Auto Scan IP Cameras in local network.
Buzzer will beep (long).
Camera Echo function- Press scan button for 0.5 second Echo IP Camera found (1 beep for 1st camera found,
2  beeps for 2nd, 3 beeps for 3rd, 4 beeps for 4th).
Buzzer will beep (short).
Reset button Press reset pin for 10 seconds Reset to factory default.
Buzzer will beep (long).
